Product Advantages
Use a wide range of temperature, using pure oyster sauce as the base oil, -50 ℃ +200 ℃.
Applicable to all kinds of soft rubber materials (rubber, silicone, PE, PVC, etc.).
Excellent oxidation resistance.
Anti-wear, good pressure resistance and damping.
High adhesion and low temperature damping.
Comply with international safety standards such as FDA, ASTM-F963, 16P, ROHS and reach standards.
Characteristic
| Test Items | BX-602/F | Test Methods |
| Colour | Transparent color | IP196 |
| Base oil | Compound oyster sauce (900,000 cst) |
|
| Penetration | 265-295 | GB/T 269 |
| Consistency value (NLGI) | 2 | GB/T 269 |
| Working temperature ℃ | -50℃ to +200℃ |
|
| Drop point ℃ | no | GB/T 3498 |
| Copper corrosion (100 ℃ / 24Hrs) | qualified | GB/T 7326 |
| Four ball test (40kg/1 Hrs /1200rpm/75℃) | qualified | GB/T 0202 |
| Viscosity level | Medium viscosity |
|
Temperature and torque value changes
| BX-602/F | Ambient temperature | 50℃ | 35℃ | 25℃ | 15℃ | 5℃ | 0℃ | -10℃ | -20℃ |
| Torque value | About 110 | About 112 | About 115 | About 118 | About 125 | About 130 | About 140 | About 150 |
Use
Suitable for all kinds of large, medium and small gear transmission structures.
Good water resistance, suitable for all kinds of water supplies.
Moderate damping force and stable high and low temperature performance.
It is necessary to dampen various types of rotation or up and down sliding parts of slow vibration resistance.
Low-temperature starting transmission structure.
Standard model: BX-602/F
Packing specification: 15KG (plastic barrel)
Storage: indoor, normal temperature, avoid direct sunlight
The above information is for reference only. The actual performance and application are subject to the customer test results. Please pay attention to the test. Please use it after the test.
